XY Piezo Nanopositioning Aluminum Stage

The NPS-XY-100A Nanopositioning stage is a piezo scanned flexure-guided stage with integrated capacitance sensors capable of sub-nanometer resolution and reproducibility. The stage is made of aluminum. The unique isostatic mounting system ensures that stresses from mounting the stage are properly relieved, and the center of the stage is the coordinate reference point.

Applications for the NPS-XY-100A Nanopositioning stage include atomic force microscopy (AFM), scanning probe microscopy (SPM), and near-field scanning optical microscopy (NSOM).

The NPS-XY-100D  two asix 100µm x 100µm stage is made of aluminum. It includes 4 corner mounting for simple installation.

Stage Specifications:

• Axis: XY
• Range: 110µm XY
• Position Noise: 0.14nm
• Repeatability: 0.5nm
• Linearity: 0.003%
• Step Settle: 4ms
• Material: Aluminum
• Size: 100mm L x 100mm W x 23mm H
• Suggested controller: Prior NPC-D-6330

View the NPS XY Piezo Stage Aluminum Datasheet.

NOTE: This item is not returnable.

Prior Part # QGNPS-XY-100D
