SPECTRA Light Engine: 8 Solid-State Light Sources

In Lumencor’s SPECTRA light engine, eight individually addressable solid-state light sources deliver unprecedented performance. Each color band provides on the order of a half a watt of optical power at the end of a liquid light guide. The constituent light sources include LEDs, Lumencor’s proprietary luminescent light pipes and lasers. The outputs of the sources are refined by bandpass filters and merged into a common optical train directed to the light output port on the front panel. The light output port has a built-in adapter for connection to microscopes and other bioanalytical instruments through a standard, 3mm diameter liquid light guide, LLG. TTL trigger inputs are provided for all eight sources for applications requiring fast (10 microsecond) switching.

• Sources: 8 solid state sources including LEDs, lasers and proprietary luminescent light pipes.
• Wavelength Range: 380 - 750nm
• Bandpass Filters: Integrally installed bandpass filters for spectral output refinement.
• Output Power: -500mW per color band +/- 10% through a 3mm liquid light guide.
• Light Delivery: 3mm diameter, 2m length liquid light guide. Liquid Light Guide sold separately, see below for options.
• Control Interface: Source selection, light output on/off and intensity via serial interface (USB B and RS232), Ethernet, and TTL (DB15) control ports. Source selection and light output on/off via TTL. Includes USB and ethernet control cables, DC power supply and cord. Liquid light guide (3mm diameter) sold separately.
• Software: Onboard GUI or PC-based image acquisition software.
• Power Requirements: 220 W (24V DC/9.2A) power supply included.
• Size/Weight: W x L x H = 145mm x 340mm x 203mm (5.7" x 13.4" x 8"), 19.1lbs.
• Warranty: 18 Months
• Optional Accessories: 8-channel breakout cable for TTL triggering. Light engine control pod.
