Reticle Grid 0.1mm Squares 100 Total Labeled
Reticle Grid 0.1mm Squares 100 Total Labeled
Reticle Grid 0.1mm Squares 100 Total Labeled

Reticle Grid 0.1mm Squares 100 Total Labeled

No reviews yet Write a Review
KR-430A glass eyepiece reticle. Grid 1mm x 1mm. 100 squares total (10x10). Labeled numbers vertical (1-10) and letters horizontal (A-J). Diagonal = 1.41mm. Avai…

Read more
SKU: KR430A
Measurement: Metric
Square Size: 0.1mm
$125.00
Hurry up! Current stock:
icon Share icon Share
Request a quote
Description

KR-430A glass eyepiece reticle. Grid 1mm x 1mm. 100 squares total (10x10). Labeled numbers vertical (1-10) and letters horizontal (A-J). Diagonal = 1.41mm. Available in a variety of diameters; select when ordering.

  • Each Square: 0.1mm when using 1x objective
  • Lines: Chrome deposition
  • Chamfer: 0.010" - 0.020"
  • Flatness: 2 waves or better
  • Centering: Within 0.005"
  • Glass Thickness: 1.5mm+/-0.1mm
  • Surface Quality: 20/10
  • Parallelism: 2 min.

NOTE: This is a special order product. Please allow 2-3 weeks for delivery. This item is not returnable.
