The Fein Optic RB40-PHFL phase contrast fluorescence microscopes are designed for a full range of fluorescence and phase contrast microscopy.
- RB40-TF Frame: Microscope frame for transmitted light with coaxial fine and coarse focusing with 2µm graduations and tension control. 100~240V built-in power supply.
- Objective Lenses: Reversed quintuple nosepiece with slot for analyzer holds the following included DIN Infinity Corrected Optical System (ICOS) Objectives:
- Plan Phase 10x Objective, NA 0.25, WD 12.1mm
- Plan Phase 20x Objective, NA 0.40, WD 1.5mm
- Plan Phase 40x Objective, NA 0.65, WD 0.36mm
- Plan Phase 100x Objective, NA 1.25, WD 0.18mm, Oil Immersion
- Plan Semi Apochromat Fluor 100x Objective, NA 1.25, WD 0.21mm, Oil Immersion.
- Viewing Head: Trinocular head, with 30° eyetubes. Interpupillary adjustment from 50-75mm. Beam splitter positions of 100/0 and 0/100.
- Eyepieces: PL-WF 10x Widefield, plan eyepieces, FN22. Left eyepiece has diopter. Accepts 26mm diameter reticle.
- Total Magnification: 40x, 100x, 400x and 1000x.
- Specimen Stage: 175 x 145mm mechanical stage with 76mm x 50mm X-Y travel range. Precision 0.1mm. Low position right-hand coaxial controls.
- Illumination: High intensity 5W LED Koehler transmitted light system provides a bright and uniform field for each magnification. Voltage 100~240V.
- Fluorescence: Fluorescence illumination attachment with six position filter turret. Metal halide illuminator with liquid light guide and collimating adapters.
- Fluorescence Filter Sets: Includes UV/DAPI, GFP/FITC, RFP/TRITC filter cubes.
- Light Focusing: Phase turret condenser with BF, PH1, PH2, PH3 and PH4 stops with iris diaphragm. Includes green interference filter and phase centering telescope.
- Size: 9.8" (250mm) W x 18.2" (463mm) D x 16" (408mm) H
- Warranty: 5 years
