The Prior Scientific ProScan III controller is compact and modular and is capable of controlling a motorized stage, a focus motor, filter wheels, and shutters with the speed, accuracy, and precision required by automated and demanding applications. Four programmable TTL inputs and outputs allow the unit peripherals or external cameras to be controlled by TTL. The advanced internal software allows for simple control of all accessories via RS232 or USB, and a SDK is supplied for easy integration into third party software. Access to acceleration, speed, and even drive current is also made available for more advanced users to allow total customization of the unit.
ProScan III Specifications:
- Stage Speed Control: Up to 300mm/s
- Step Size Control: From 0.01µm for XY, 0.002µm for Z
- Repeatability (Focus/Stages): <1µm
- Limit Switches: Adjustable in X and Y. Optical and mechanical available in Z.
- Base Unit Accommodation: 3 Axis System. Additional functionality can be added with modular sections.
- Control Ability: Up to 16 Axes by expanding system with ancillary boxes.
- Configuration Options: Modular system additions can expand vertically or horizontally (select when ordering).
- COM Port Communications Protocol: 8 bit word, 1 stop bit, no parity
- Computer Interface: USB (Virtual COM), RS232C
- Power: Universal 110~240V, 50-60Hz
- Dimensions: 177mm x 177mm x 177mm
- Weight: 3 kg (6.7 lbs)
- Warranty: 3 Years
View the ProScan III Controller Brochure
NOTE: This item is not returnable.
Prior Scientific Part #s H31XYZE, H31XYZEF, V31XYZE, V31XYZEF.
