Mitutoyo Metric Screw Pitch Gage 0.25-25mm
Mitutoyo Metric Screw Pitch Gage 0.25-25mm
Mitutoyo Metric Screw Pitch Gage 0.25-25mm

Mitutoyo Metric Screw Pitch Gage 0.25-25mm

No reviews yet Write a Review
This metric screw pitch gage has the thread pitch size stamped on each gage and has the following specifications: Metric Screw Pitch Gage: 60º Range: 0.25 - 2.…

Read more
SKU: 188-153
$42.00
Hurry up! Current stock:
icon Share icon Share
Request a quote
Description

This metric screw pitch gage has the thread pitch size stamped on each gage and has the following specifications:

  • Metric Screw Pitch Gage: 60º
  • Range: 0.25 - 2.5mm
  • 28 Leaves: 0.25, 0.30, 0.35, 0.40, 0.45, 0.50, 0.55, 0.60, 0.65, 0.70, 0.75, 0.80, 0.85, 0.90, 1.00, 1.10, 1.20, 1.25, 1.30, 1.40, 1.50, 1.60, 1.70, 1.75, 1.80, 1.90, 2.00, 2.50mm

Technical Data:

TPI Metric  Accuracy
 Pitch (mm) Angular (minutes)
4-6  6.35-4.23  +/-0.05  +/-35
7-12 3.63-2.12   +/-0.05  +/-40
13-25  1.95-1.02   +/-0.05  +/-45
26-48  0.98-0.53   +/-0.05  +/-50
60  0.42   +/-0.05  +/-60


Mitutoyo part #: 188-153

NOTE: This item is not returnable.
