Mitutoyo LSM-503S Standard Laser Scan Micrometer

No reviews yet Write a Review
This laser scan micrometer is a general purpose laser micrometer with measurement range of 0.3mm to 30mm. Provides high accuracy with a linearity of +/-1.0&micr…

Read more
SKU: 544-536
$12,519.00
Hurry up! Current stock:
icon Share icon Share
Request a quote
Description

This laser scan micrometer is a general purpose laser micrometer with measurement range of 0.3mm to 30mm. Provides high accuracy with a linearity of +/-1.0µm over the entire measurement range and +/-(0.6+0.1ΔD)Δµm in the narrow range. Excellent repeatability of +/-0.1µm. NOTE: you will need either the LSM-5200 compact display unit or the LSM-6200 display unit to read the output data.

Contact Microscope World for information on having this instrument calibrated.

  • Measuring Range 0.3 - 30mm (0.012 - 1.18")
  • Resolution (selectable) 0.02 to 100µm (0.000001 - 0.005")
  • Repeatability +/-0.11µm
  • Accuracy +/-1.0µm whole range
  • Measuring Area 10x30mm (0.3 to 30mm)
  • Scanning Rate 3200 scans/s
  • Laser Wavelength 650nm (visible), IEC Class 2/, FDA Class II
  • Laser Scanning Speed 226m/s
  • Protection Level IP64
  • Display Unit None included, options listed below.



    Mitutoyo part #: 544-536

NOTE: This item is not returnable.
