Mitutoyo Carbide Blade Point Probe Tip Stylus Mu Checker

This blade point stylus fits the Mu checker cartridge head probes 519-331 and 519-348, and the tip is made of carbide. This stylus is convenient for measuring a cylindrical workpiece. This stylus has the following dimensions (refer to the second image above):

• Blade thickness 0.6mm
• Blade width 2mm
• Blade length 2.5mm
• Body length 10mm
• Thread size M2.5 x 0.45 x 5mm

NOTE: This item is not returnable.

Mitutoyo part # 21AZB768, replaced part 120062
