Meiji EMZ13-PK-MCLS-RING Stereo Zoom Pole Stand LED Ring Light Microscope

Meiji EMZ13-PK-MCLS-RING Stereo Zoom Pole Stand LED Ring Light Microscope

No reviews yet Write a Review

Meiji stereo microscope system EMZ13-PK on a pole stand with a LED ring light provides 10x - 70x magnification. The microscope system includes the following: M…

SKU:

$4,095.00 - $4,415.00

Hurry up! Current stock:

Quantity:

Request a quote

Description

Meiji stereo microscope system EMZ13-PK on a pole stand with a LED ring light provides 10x - 70x magnification. The microscope system includes the following:

Microscope Body: Select when ordering from a stereo zoom binocular or trinocular body, rotatable 360°, eyetube inclination 45°. Interpupillary distance adjustable from 54mm - 75mm. Dioptric adjustment on the left eyetube. Trinocular body directs light to right eyetube and trinocular tube simultaneously.
Objectives: Zoom range of 1.0x - 7.0x
Zoom Ratio: 7:1
Zoom Control: Dual, graduated, bilateral mount
Working Distance: 90mm
Magnification: 10x eyepieces are included. Additional eyepieces are available for purchase separately.
Available eyepiece magnifications: 12.5x, 15x, 20x, 30x. (All accept 25mm reticle except for 5x & 30x eyepieces).
Supplemental objectives and eyepieces:
- See magnification chart below for options for extending WD and magnification.
- Extended Magnification Range: 3x - 315x
- Extended Working Distances: 48mm - 230mm
Microscope Stand: Pole microscope stand has base dimensions of 330mm (13") x 265mm (10.4"). The stand height is 280mm (11"). The pole diameter is 20mm. The stand includes stage clips and a reversible black/ white stage plate with a diameter of 94.5mm.
Focusing Holder: Rack and pinion mount allows for smooth, precise coarse focusing.
Illumination: Includes a SCHOTT MC-LS Light box with a ring light.
Warranty: Meiji Techno warrants the microscope body against defects in material and/or workmanship for the life of the instrument from the date of original purchase to the original purchaser.

Meiji Stereo EMZ-13 Microscope Magnification Chart

Aux Lens	Working Dist. (mm)	SWF10x Eyepieces		SWF12.5x Eyepieces		SWF15x Eyepieces		SWF20x Eyepieces		SWF30x Eyepieces
Aux Lens	Working Dist. (mm)	Total Mag.	Field Diam. (mm)	Total Mag.	Field Diam. (mm)	Total Mag.	Field Diam. (mm)	Total Mag.	Field Diam. (mm)	Total Mag.	Field Diam. (mm)
None	90	10x- 70x	22- 3.1	12.5x- 87.5x	17.6- 2.5	15x- 105x	14.7- 2.1	20x- 140x	11- 1.6	30x- 210x	7.3- 1.1
0.3x	230	3x- 21x	73.3-10.5	3.75x- 26.25x	58.7-8.34	4.5x- 31.5x	48.9-7	6x- 42x	36.7-5.2	9x- 63x	24.4-3.5
0.44x	167	4.4x- 30.8x	50- 7.1	3.85x- 24.75x	40- 5.7	6.6x- 46.2x	33.3- 4.8	8.8x- 61.6x	25-3.6	13.2x- 92.4x	16.7- 2.4
0.5x	139	5x- 35x	44-6.3	4.37x- 28.12x	35.2- 5	7.5x- 52.5x	29.3- 4.2	10x- 70x	22-3.1	15x- 105x	14.7-2.1
0.75x	92	7.5x- 52.5x	29.3- 4.2	6.56x- 42.18x	29.3-3.4	11.3x- 78.75x	19.6- 2.8	15x- 105x	14.7- 2.1	22.5x- 157.5x	9.8- 1.4
1.5x	48	15x- 105x	14.7- 2.1	13.12x- 84.37x	14.7- 1.7	22.5x- 157.5x	9.8- 1.4	30x- 210x	7.3- 1.05	45x- 315x	4.9- 0.7

EMZ13B-PK-MCLS-RING, EMZ13T-PK-MCLS-RING
