Jenoptik ProgRes Gryphax Kapella Color Microscope Camera

Please contact Microscope World for a quote or further information

The Jenoptik ProgRes Gryphax USB 3.0 Kapella camera is a 2.3 megapixel color microscopy camera.

View a chart comparing the Jenoptik Gryphax microscopy cameras here.

Camera Specifications

• CMOS Sensor: 2.3 megapixels, 1/1.2" Sony back illuminated color sensor with IR cut filter
• Pixel Size: 5.86 µm x 5.86 µm
• Image Resolution: 1920 x 1200
• Frame Rate: 60 fps at 1920 x 1200
• Microscope Connection: C-Mount thread for connecting to your microscope-specific c-mount adapter.
• A/D Conversion: 12 Bit (4096 grey values)
• Software: Includes ProgRes GRYPHAX Software.
• Size/Weight: 85mm x 75mm x 50mm, 400g
• Warranty: 2 years for camera, 1 year for software.
• View the Kapella Data Sheet

Computer Requirements

• Intel i7 (Quad-Core) processor or comparable / 8GB RAM
• WIN 10 (build 1903 or newer), MacOS Catalina / Big Sur, LINUX Ubuntu 18.04 LTS
• USB 3.0 integrated, no extra power supply required
• Monitor resolution of 1920 x 1200 or higher
