The Inspectis F30s HD Basics Software gantry system features the F30s HD digital microscope with 30:1 motorized zoom on an industrial grade XY travel table top …

Read more
SKU:
$12,769.00 - $13,718.00
Hurry up! Current stock:
Request a quote
Description

The Inspectis F30s HD Basics Software gantry system features the F30s HD digital microscope with 30:1 motorized zoom on an industrial grade XY travel table top gantry stand, 21" HD monitor, computer, and full HD HDMI USB3.0 image and capture device. This system includes Inspectis Basics Software with functions for image view, capture, annotation, line measurement and has pre-calibrated magnifications. Explore more features of Inspectis Basics Software.

  • Video Output: FHD 1080p at 60fps switchable to Full HD 1080p at 50fps by remote control panel. HDMI type A female connector on rear panel.
  • Imager: 3.2 MP, 1920(H) x 1080(W) 16:9 format progressive scan
  • Working distance: 230mm
  • Lens: High resolution motorized 30:1 zoom with auto-focus, iris control and pre-calibrated optics.
  • Camera and lens control: Iris, Zoom, Auto Focus on/off, white balance. Optional Inspectis 2 Pedal Foot Switch and Inspectis Advanced Camera Remote Control can be purchased for hands free control of the camera. Hands free control requires both of these products.
  • Environmental Protection: Camera housing is hermetically sealed to prevent entry of dust or other contaminates. ESD protection built-in to camera housing.
  • Capture Device: USB image and video capture device for recording and storing images and videos.
  • Illumination: Inspectis White LED Ring Light with 8 high power LEDs with 5800 K color temperature and detachable diffuser. Illumination controls for soft, smooth light adjustment. The ring light is powered directly through the AUX output of the Inspectis digital microscope.
  • Stand: Industrial grade XY travel table top gantry stand available in two sizes with optional 4 direct tilt attachment:
    • Standard: X-travel 100mm - 750mm / Y-travel 100mm - 550mm
    • Long range Y- travel: X-travel 100mm - 750mm / Long range Y-travel 551mm  - 800mm.
    • Optional 4 direction tilt unit for +/- 30º slope angels. Designed for side viewing of samples.
    • Larger stand sizes and motorized options are available. Contact Microscope World for details.
  • Computer / Monitor: Computer with 21" HD monitor with 1920 x 1080 resolution.
  • Software: Inspectis Basics Software features:
  • Live image with freeze frame
  • Capture still images and video
  • Digital zoom
  • Calibrated measurement thru zoom range
  • Pre-set for different magnification levels
  • Lens distortion correction
  • Flip image, vertical & horizontal
  • Distance measurement
  • Annotation
  • Object count
  • Overlay crosshair or grid
  • Saved image folders
  • Input / Output: HDMI video output, 5PMiniDin power input, 8P MiniDin for communication.
  • Manufactured in Sweden.
Zoom Factor Magnification on 21" LCD Optical Magnification
 1 1.7 0.8
2 3.3 1.6
3 5.0 2.4
4 6.4 3.1
5 7.9 3.8
6 9.6 4.6
7 11.2 5.4
8 12.7 6.1
9 14.1 6.8
10 15.8 7.6
11 17.2 8.3
12 19.1 9.2
13 20.4 9.8
14 22.0 10.6
15 23.7 11.4
16 25.1 12.1
17 26.6 12.8
18 28.3 13.6
19 29.3 14.1
20 31.4 15.1
21 32.6 15.7
 22 33.9 16.3
23 36.6 17.6
24 38.2 18.4
25 39.9 19.2
26 40.7 19.6
27 41.8 20.1
28 44.1 21.2
29 45.3 21.8
30 46.8 22.5
30 w/ +1  58.2 28
30 w/ +2 66.5 32
31 w/ +3 74.8 36
31 w/ +5 93.5 45
 32 w/ +10 141.3 68

NOTE: This item is not returnable.
